820W solar LED grow light Gavite CT 1930e LED replace 1000W DE HPS
Applications:
● 3years warranty .
● Mainly used for indoor hemp/Cannabis/Green house planted .
● Customized white light spectrum, suitable for cultivating seedlings
Features:
● Independent signals can control an unlimited number of grow light.
● DS controller or other abrand controller can be adapted(pwm signal).
● Uses standard RJ14 data cables.
● Full spectrum operation and selectable spectral operation.
● Low temperature rise heat sink provides high PPF output.
● Energy saving,long life design,up to 30000H,Equivalent to HPS1000W
● Power and heat dissipation split type.
Application:
Product Specifications:
| Product Name | 780W LED Grow Light |
| Model number | DS100-M2-780 |
| Power | 780W +/-5% |
| Input voltage | 110-277VAC 50/60Hz |
| LED Driver | UL CE Driver |
| Lumen | 117000LM |
| Lumen efficiency | 153LM/W |
| CRI | >90 |
| PPF (380-780nm) | 2028μmol/S |
| EFF | 2.6μmol/J |
| Color | Full spectrum white light +660nm+460nm |
| Coverage | 4x8ft |
| Mounting height | ≥ 6″ Above canopy |
| Supplementation time | Vegetative Stage: 12 – 14 hours on; Flowering Stage: 9-12 hours on; Fruiting Stage: 7-8 hours on. |
| PF | >0.95 |
| THD | <20% |
| Module | 2 |
| Angle | 90×120° |
| Housing color | Silvery |
| Material | Aluminum |
| IP | IP44 (Indoor using) |
| Lifespan | >50,000H |
| Working Temperature | -25°C~+40°C |
| Operating Humidity | <90% |
| Storage Temperature | -35°C~+80°C |
| Input voltage（AC) | 108Volt 208Volt 240Volt 277Volt |
| Input current at 100% | 7.3A 3.9A 3.6A 2.95A |
| Input power at 100%: | 780W 780W 780W 780W |
| Package Carton | 770*355*160mm |
| Dimension | 722*316*111mm |
| Gross Weight | 31.5kg |
| Net Weight | 29.5kg |
Dimension:
Spectrum:
PPFD Distribution: 4x4ft mounting Height:60cm/90cm
Use Daisy Chain Function
ATTENTIONS：
1: When use the master controller,Adjust the knobs of all lights to the cascade position:Turn the knob to the left(100% position),
2: Use RJ45 cable to connect the DIM OUT of the main controller to the INLET port of the light（For multi-channel）, CHI for one channel light.
3: For more operation instructions on the main controller, please refer to the attachment
780W LED GROW LIGHT-LENS
