Features:
● Availble in different color shades of white.
● LED lamps suitable for simple (retrofit) replacement of 40w Incandescent lamps.
● Temperature range:﹣20 ℃ to 45℃.
● Suitable for indoor application in open luminaires.
● Very suitable for food processing and pharmaceutical applications, it can withstand strict daily flushing and help factories meet strict hygiene standards.
● Providing high borosilicate tubes, PC, PMMA, and shell materials that can adapt to various acidic and alkaline environments.
● Built in serial wires, suitable for serial connection of lighting fixtures, with a maximum power of 1500W.
● In the case of a single lamp, select a three color temperature of 3000/4000/5000K through an external switch.
Application:
Factories, workshops, warehouses, corridors, sports halls, exhibition halls, food processing farms, breeding farms.
Product Specifications:
| Product Name | 20W LED TRI-PROOF Light |
| Model number | DS-C-20-06 |
| Power | 20W +/-5% |
| Input voltage | 220-240VAC 50/60Hz |
| LED Driver | CE TUV ENEC UKCE Driver OSRAM or LFD |
| Lumen | 3000-3200LM |
| Lumen efficiency | 150LM/W |
| CRI | >80 |
| SDCM | <4 |
| Color | 3000k-6000k |
| PF | >0.9 |
| THD | <20% |
| Surge Capability (L-N) | 6kv |
| Surge Capability (LN-GND) | 6kv |
| Angle | 120° |
| Housing color | white |
| Material | PC+Aluminum |
| End cap | 304 or 316 option |
| IP | IP69K (Indoor using) |
| Lifespan | >50,000H at 25°C |
| Working Temperature | -25°C~+40°C |
| Operating Humidity | <90% |
| Storage Temperature | -35°C~+80°C |
| Input voltage（AC) | 180Volt 230Volt 265Volt |
| Input current at 100% | 117ma 95ma 84ma |
| Input power at 100%: | 20W 20W 20W |
| Package Carton | 610*270*270mm |
| Dimension | D78*600mm |
| Gross Weight | 11.2kg/9pcs |
| Net Weight | 9.9kg |
Dimension:
Photometric diagrams:
option:
The number of loads on the circuit breaker
LED TRI-PROOF LIGHT-IP69K
